Product Summary
The US1M is a 1.0A surface mount ultra-fast rectifier.
Parametrics
US1M absolute maximum ratings: (1)Peak Repetitive Reverse Voltage: 1000 V; (2)Working Peak Reverse Voltage : 1000 V; (3)DC Blocking Voltage (Note 4): 1000 V; (4)RMS Reverse Voltage VR(RMS): 700 V; (5)Average Rectified Output Current @ TT = 75℃: 1.0 A; (6)Non-Repetitive Peak Forward Surge Current 8.3ms: 30 A; (7)Single Half Sine-Wave Superimposed on Rated Load: 30 A.
Features
US1M features: (1)Glass Passivated Die Construction; (2)Ultra-Fast Recovery Time for High Efficiency; (3)Surge Overload Rating to 30A Peak; (4)High Current Capability; (5)Ideally Suited for Automated Assembly; (6)Lead Free Finish/RoHS Compliant; (7)Green Molding Compound (No Halogen and Antimony).
Diagrams
