Product Summary

The K6X4016T3F-TF55 is a 256Kx16 bit Low Power and Low Voltage CMOS Static RAM. The device is fabricated by advanced CMOS process technology. The K6X4016T3F-TF55 supports various operating temperature range and have 44-TSOP2 package type for user flexibility of system design. The K6X4016T3F-TF55 also supports low data retention voltage for battery back-up operation with low data retention current.

Parametrics

K6X4016T3F-TF55 absolute maximum ratings: (1)Voltage on any pin relative to Vss, VIN,VOUT: -0.2 to VCC+0.3(max. 3.9V); (2)Voltage on Vcc supply relative to Vss, VCC: -0.2 to 3.9V; (3)Power Dissipation, PD: 1.0W; (4)Storage temperature, TSTG: -65 to 150℃; (5)Operating Temperature, TA: 0 to 70℃.

Features

K6X4016T3F-TF55 features: (1)Process Technology: Full CMOS; (2)Organization: 256K x16; (3)Power Supply Voltage: 2.7~3.6V; (4)Low Data Retention Voltage: 2V(Min); (5)Three State Outputs; (6)Package Type: 44-TSOP2-400F.

Diagrams

K6X4016T3F-TF55 pin connection
