LT3430EFE#PBF

LT3430EFE#PBF, monolithic buck switching regulator, 60V, 3A, 200kHz, TSSOP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $2.30~2.30 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
1 ~ 1000 :	2.30 / Piece

PartNumber:: LT3430EFE#PBF

Brand:: Linear Technology - Linear | Pack: TSSOP | D/C: 11+

Availability:: Supply Ability: 10000/Day Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Not exactly what you want? Post a quick Buying Request!

Sold By

Ms. Erin's store

(Hong Kong)

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2013-05-27

From Other Seller

Part Number:LT3430EFE#PBF
US $2.30 - 2.30
Quantity:

piece

Product Summary

The LT3430EFE#PBF is a 200kHz monolithic buck switching regulator that accepts input voltages up to 60V. A high efficiency 3A, 0.1W switch is included on the die along with all the necessary oscillator, control and logic circuitry. A current mode architecture provides fast transient response and excellent loop stability. Applications are (1)Industrial and Automotive Power Supplies; (2)Portable Computers; (3)Battery Chargers; (4)Distributed Power Systems.

Parametrics

LT3430EFE#PBF absolute maximum ratings: (1)Input Voltage (VIN): 60V; (2)BOOST Pin Above SW : 35V; (3)BOOST Pin Voltage : 68V; (4)SYNC Voltage : 7V; (5)SHDN Voltage : 6V; (6)BIAS Pin Voltage : 30V; (7)FB Pin Voltage/Current : 3.5V/2mA; (8)Operating Junction Temperature Range; (9)LT3430EFE (Note 8): –40°C to 125°C; (10)LT3430IFE (Note 8): –40°C to 125°C; (11)Storage Temperature Range : –65°C to 150°C; (12)Lead Temperature (Soldering, 10 sec): 300°C.

Features

LT3430EFE#PBF features: (1)Wide Input Range: 5.5V to 60V; (2)3A Peak Switch Current; (3)Small Thermally Enhanced 16-PiTSSOP Package; (4)Constant 200kHz Switching Frequency; (5)Saturating Switch Design: 0.1W; (6)Peak Switch Current Maintained Over Full Duty Cycle Range; (7)Effective Supply Current: 2.5mA; (8)ShutdowCurrent: 30mA; (9)1.2V Feedback Reference Voltage; (10)Easily Synchronizable; (11)Cycle-by-Cycle Current Limiting.
