Product Summary
The HD9P6409-9 Manchester Encoder-Decoder (MED) is a high speed, low power device manufactured using self-aligned silicon gate technology. The HD9P6409-9 is intended for use in serial data communication, and can be operated in either of two modes. Manchester code is used in magnetic tape recording and in fiber optic communication, and generally is used where data accuracy is imperative. Because it frames blocks of data, the HD9P6409-9 easily interfaces to protocol controllers.
Parametrics
HD9P6409-9 absolute maximum ratings: (1)Supply Voltage: 7.0V; (2)Input, Output or I/O Voltage: GND -0.5V to VCC +0.5V; (3)Storage Temperature Range: -65°C to +150°C; (4)Maximum Lead Temperature (Soldering 10s): +300°C; (5)Input Rise and Fall Times: 50ns Max.
Features
HD9P6409-9 features: (1)Converter or Repeater Mode; (2)Independent Manchester Encoder and Decoder Operation; (3)Static to One Megabit/sec Data Rate Guaranteed; (4)Low Bit Error Rate; (5)Digital PLL Clock Recovery; (6)On Chip Oscillator; (7)Low Operating Power: 50mW Typical at +5V; (8)Available in 20 Lead Dual-In-Line and 20 Pad LCC Package.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 HD9P6409-9 |
Intersil |
IC MED MANCHESTER 1MHZ 20-SOIC |
Data Sheet |
Negotiable |
|
||||||||
 |
HD9P6409-9Z |
Intersil |
Encoders, Decoders, Multiplexers & Demultiplexers W/ANNEAL ENC/DEC 1MHZ 20 -40+85C |
Data Sheet |
|
|
||||||||
|
HD9P6409-9Z96 |
Intersil |
Encoders, Decoders, Multiplexers & Demultiplexers W/ANNEAL ENC/DEC 1MHZ 20 -40+85C |
Data Sheet |
|
|
||||||||
